Features

• Reduced Machine width of 850 mm.
• Take up, Pre take up, Cam drive by means of toothed belt wheels for reduced noise & power.
• Anti patterning by means of Electro Mechanical System. Stepless variation control by means of Electronic Timer.
• Isolated spindles & long separators to prevent end lashing.
• Outer pot with simple clamp for easy attachment / detachment according to the processing yarn counts.
• Sturdy cradle system ensures quality delivery package.
• Four spindle drive system for reduced power consumption.
• Hollow shaft for low power consumption.
• Provision for normal package / soft package / dye package winding.

OPTIONALS

• Cradle lifting device- For disengaging the delivery package during
  end breakage.
• Outer pot- For balloon control.
• Bunching device- For providing tail end.
• Top tray- For storing yarn package.
• Creeping device- For producing dye package.
• Waxing device- For hosiery yarns.

CRADLE

Easily adjustable cradle pressure for hard/soft packages In the event of yarn breakage, the cradle is lifted by means of mechanical system Adjustable cradle to suit different conicity of delivery package

SPINDLE AND OUTER POT

Versatile spindle construction for processing wide range of yarn counts Isolated spindles to prevent end lashing Four spindle drive with hand brake system Balloon limiter enables processing of extended range of counts. However delicate materials should be processed without balloon limiter Easily attachable/detachable according to the process requirement.

DRIVE SYSTEM

• All the drive mechanism are by means of toothed belts.
• Less Maintenance and no lubrication required
• Electronically controlled anti-patterning device is provided for high quality delivery package.
